| Model | DA-20 |
| Control | Touch Panel |
| Handpiece | LED Detachable Pieze Handpiece PH-1 ×1 |
| Operating Mode | G/P/E |
| Water Tank | 800mL ×1 |
| External Water Hose | Unavailable |
| Foot Pedal | Wireless Foot Pedal (IPX4) ×1 Wired Foot Pedal (IPX1) ×1 |
| Scaler Tip | E14×1,P1×2,G2×1,G1×2,G4×2,E1×1,P4×1,(10pcs in total) |
| Weight | 1.8kg |
| Input Voltage | 230VAC 50Hz |
| Input Power | 35VA |
| Vibration amplitude | Minimum: 1 um; deviation -50% Maximum: 100 μ m; deviation +50% |
| Output half-excursion force | Minimum: 0.1 N; deviation -50%. Maximum: 5 N; deviation +50% |
| Frequency | 18kHz～45KHz |
| Tip output power | 3W～20W |
| Operating mode | Continuous running |
| Tips Hardness | 50HRC |
| Main unit size | 285mm*155mm*145mm |
| Packing Size | 475mm*170mm*360mm |
| Storage Environment | Temperature：-20℃～55℃ Relative humidity：≤90% Atmospheric pressure：70kPa～106kPa |
| Working Environment | Temperature:5℃～40℃ Relative humidity:≤80% Atmospheric pressure: 70kPa～106kPa Applicative range of power supply and voltage: 230VAC,50Hz The maximum inlet pressure of handpiece: 0.5MPa See the specific specifications on the label. |
| Life time | 10 year |
| handpiece can be sterilized | 134℃ and 0.22 MPa pressure |
