DM-1

Technical Parameters

Basic parameters

Model DM-1
Charging Input DC 5V 1A
Battery 3.7V / 1050mAh
Speed Range 150 rpm – 800 rpm
Torque Range 0.6 N·cm – 3.9 N·cm
Buzzer Alarm Audible alert when the file is less than 2 mm from the apex
Device Weight 100g
Device Dimensions 90 × 90 × 235 mm
Packing Size 200 × 185 × 93 mm
Electric Shock Protection Type Class II Equipment
Applied Part Protection Type B Applied Part
Ingress Protection Rating Ordinary Equipment (IPX0)
Operation Mode Continuous Operation
Storage Conditions Temperature: -20°C to 55°C Relative Humidity: 0% – 90% Atmospheric Pressure: 70 kPa – 106 kPa
Operating Conditions Temperature: 0°C to 40°C Relative Humidity: 10% – 85% Atmospheric Pressure: 70 kPa – 106 kPa
Service Life 5 Years
Autoclavable Parts Handpiece / File Clip / Lip Hook / Probe / Silicone Sleeve Autoclave Conditions: 134°C at 0.22 MPa
Water pressure 0.01MPa～0.5MPa (0.1bar～5bar)
Compressed air supply 5bar～6bar（0.5 MPa～0.6 MPa）
Frequency 25kHz～35KHz
Tips Hardness 50HRC
Packing Size 310*370*200mm
Storage Environment Temperature: -20℃ ～ 55℃,
Relative humidity: ≤ 90%,
Atmospheric pressure: 70 kPa ～ 106 kPa.
Working Environment a.Ambient temperature: 5℃～40℃
b.Relative humidity: ≤80%
c.Atmospheric pressure: 70kPa～106kPa
d.Temperature of Cooling liquid: 5℃～25℃
Life time 10 year
handpiece can be sterilized 134℃ and 0.22 MPa pressure


Accessories

Videos

F＆Q

  • DM-1 Maintenance Guide

    DM-1 Maintenance Guide


    I. Daily Maintenance
    1.1. Sterilize the burs before each use to prevent cross-infection.
    1.2. Clean the file on the chuck before and after each use and ensure proper protection to prevent contamination or damage to internal components.
    1.3. After treatment, disinfect all parts that come into contact with the patient using disinfectant wipes (free of bacteria, fungi, and formaldehyde).
    1.4. Apply disposable protective film to cover the handpiece and screen area before treatment.
    II. Regular Maintenance
    2.1. If the device will not be used for an extended period, remove the battery and store it in a sealed container.
    2.2. Regularly clean the cable connection ports to ensure smooth and reliable contact.
    III. Disinfection Instructions
    3.1. The contra-angle, files, lip hooks, probes, and rubber sleeves must be sterilized in an autoclave before use.
    3.2. The main unit, charging base, measuring cable, and charging cable must not be sterilized using high temperature and pressure.
    IV. Precautions for Use
    4.1. When the battery is low and the indicator light flashes, charge the device promptly. If fully depleted, charge for at least 4 hours.
    4.2. Always use original accessories to ensure measurement accuracy.
    4.3. Do not touch or remove the bur while pressing the foot pedal switch.
    4.4. If using the combined ENDO amplification and apex locator function, a rubber sleeve must be applied for protection.
    4.5. Do not use chemical agents to clean the device, as they may cause damage.
    4.6. If the battery is fully charged but cannot support at least one day of operation, replace it immediately.
    V. Protection and Storage
    5.1. Handle the product with care during storage; keep it away from vibration sources and store it in a cool, dry, and ventilated environment.
    5.2. Do not store the device near toxic, corrosive, flammable, or explosive substances.
    5.3. During transportation, avoid strong impacts or vibrations. Handle with care, keep away from hazardous materials, and protect from direct sunlight and rain.
    5.4. Store the product in an environment with a relative humidity of no more than 90%, atmospheric pressure between 70 kPa and 106 kPa, and a temperature range of -20°C to 55°C.
